SCD 1300 H
SCD 1300 H Hydraulic Cylinder Head Testing Machine: It is a machine designed to detect any kind of cracks that can not be seen in the cylinder heads. After the cylinder head is attached to the 360° rotatable table, the cracks on the cylinder head are detected by immersing the heated water in the water tank with the help of heaters and using by compressed air.
| TECHNICAL SPECIFICATIONS |
SCD 1300 H |
| Maximum cylinder head length |
1250 mm
|
|
Cylinder head width |
420 mm
|
| Cylinder head height |
450 mm
|
|
Maximum cylinder head height |
350 kg
|
|
Tank capacity |
700 lt
|
|
Heater |
2x10 kw
|
|
Thermostat |
0-90 °C
|
|
|
| CODE |
STANDARD EQUIPMENTS |
ADET / QUANTITY
|
|
STD 1932 |
Glass plate 30x1000 mm |
1
|
|
STD 1933 |
Glass plate 30x500 mm | 1
|
|
STD 1934 | Hydraulic system |
1
|
|
STD 1935 | Air control clock |
1
|
|
STD 1936 | Connecting lugs |
5
|
|
STD 1937 | Control tire
| 1
|
|
STD 1938 |
Operating manual |
1
|
| |
|
|
DIMENSIONS
|
|
Length
|
2100 mm
|
|
Height
|
1550 mm
|
|
Width
|
1200 mm
|
|
DIMENSIONS WITH PACKING
|
|
Length
|
2200 mm
|
|
Height
|
1750 mm
|
|
Width
|
1300 mm
|
|
WEIGHTS
|
|
Without packing
|
700 kg
|
|
With packing
|
850 kg
|
